Durable Sewer Inspection Camera , Pipeline Video Inspection With Sonar System

China Durable Sewer Inspection Camera , Pipeline Video Inspection With Sonar System supplier

Large Image :  Durable Sewer Inspection Camera , Pipeline Video Inspection With Sonar System

Product Details:

Place of Origin: China
Brand Name: Trio-Vision
Model Number: TVS-6000

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: carton
Delivery Time: 4-8 weeks
Supply Ability: 10 sets per months
Contact Now
Detailed Product Description
Inspection Range: 100-6000mm Water Proof: IP63
Frequency: 512Hz

Sewer Pipe Inspection Sonar System Underwater Inspection Tvs-6000







TVS-6000 Sonar Pipeline Inspection System detects and pinpoints targets underwater by means of the principle of wave reflection. It, therefore, can perform pipeline inspection filled with liquid to determine the information of crack and debris in the pipe; and it is the most advanced device for pipeline inspection and assessment.

Features:

  • Complete 360 degree continuous simultaneous scan within 1s
  • Friendly software interface to operate readily
  • Data and images saved in the hard disc
  • Built-in roll and pitch angle sensors
  • Built-in cable counter interface
  • Inspect pipe profile automatically


Sonar Probe Technical Parameter



Acoustic Parameter
Acoustical frequency
2MHz

Wave width
1.1°(cone wave beam)

Lateral resolution

0.5mm (Pipe radius 125mm)
Max. inspection radius 12m
Transmit pulse width 4~20us

Receiving wave width
500KHz



Manual Cable Drum:
Counter: high precision coder( ±0.1m), cable length calculation.
Layering: manual layering
Waterproof: IP63
Durable Sewer Inspection Camera , Pipeline Video Inspection With Sonar System

SonarProf Pipe Sonar Professional Analysis Software
Support pipe cross-section in real-time representation and a full 360-degree profile extendable (IMG. 1)
Automatically generate pipe 3-D modeling and view debris and defect inside clearly (IMG. 2)
Support debris volume calculation & analysis data to be plotted easily (IMG. 3)
Automatic reporting for high efficiency report preparation (IMG. 4)

Durable Sewer Inspection Camera , Pipeline Video Inspection With Sonar SystemDurable Sewer Inspection Camera , Pipeline Video Inspection With Sonar SystemDurable Sewer Inspection Camera , Pipeline Video Inspection With Sonar System
